ENGINE ROOM:
MTU 12v2000 (1940 HP)
Stainess Steel Engine Beds
Lube Oil Change System with 45 gallon lube tank
Delta T fan system
2-55 KW Kohler Generators
2- 1,400 GPD Water Makers
Waste Treatment System
Atlas
STEERING / CONTROL:
• Hydraulic steering system
• Steering control station with complete instrumentation
• S/S rudders w/integrated zinc plates
• Dripless seal for rudder post
• High performance computer designed and machined
NiBrAl propeller
• Interior s/s steering wheel w/ Faux leather wrapped
• Maintenance free “dripless” seals for engine shaft
packing glands
• Propeller shaft Aqua 22HS.
WINDLASS / MOORING:
• Dual hydraulic windlasses, VWCLP4000
• Dual stainless steel anchors 350 lbs. from hull sides w/
250ft anchor chain (1/2" HT) & chain stoppers.
• Two vertical electric rope winches for aft deck VC
2500(Standard versus competitors’ optional)
• Reinforced anchor platform and anchoring system
• Chain counter
• Hands-free anchor chain wash system – allows for
cleaning of chain during anchor operation (Unique OA
feature)
THRUSTER / STABILIZERS:
• Sidepower™ Vector Fin (DAME 2013 award winner) 15 ft2
hydraulic stabilizer find with zero speed stabilization
function
• Sidepower’s patented “curved” fin design not only
provides lift underway it is also unique in the industry with
active “predictive” inertia control
• 55HP bow and 40HP stern thrusters.
OTHER:
• Stainless steel rails on side of engine and stainless steel
engine mounting plates (Unique Ocean Alexander
engineering affords industry leading torsional rigidity and
engine alignment assurance. Further reducing vibration
and high torque pressures)
• Color-coded piping system for easy identification
Kahlenberg™ heavy-duty horn
• All engine room and bilge spaces shall be primed and
top coated with polyurethane paint system.
• Heavy-duty commercial grade pantograph windshield
wipers & washers w/ intermittent function
• Detailed stringers in engine room & lazarette
• Ocean Alexander proprietary “dry bilge ventilation
system” with dedicated bilge exhaust to outside. This
provides constant airflow to keep the bilges dry and
mildew free. Any moisture from condensation is
evacuated outside the yacht to keep a clean and
healthy cruising environment
• Ocean Alexander design in oversized shafts, rudder and
other drive train systems typically one-class larger than
competition. Superior handling, longevity is ensured with
Ocean Alexander drive-train systems
FUEL SYSTEM:
Sight gauges for all tanks
• 4.5mm thickness 5052 Aluminum fuel tanks with sight
gauges and tested to International Standards 33CFR
510(a) w/ high and low fuel level alarm system
• Dual Racor® fuel/water separator with Y-valves for
generators
• Gulfcoast™ Fuel polishing system based on US Military
Abrahams-M1 tank design (standard versus competitors’
optional)
• Dual MTU® fuel filter w/ remote readout of filter
performance. (Unique OA standard, usually found on
150’+ vessels)
• Filler for fuel tanks on both sides with individual tank vents.
(Unlike others where fueling is only possible on 1 side. This
unique OA feature allows for concurrent and faster
fueling & negates need to move boat to complete
fueling)
• Fuel system with venting and “catchment system”
designed for burps or overflow accidents (Unique OA
feature. Often ignored by competitors which can lead to
high fines and insurance cancellation)
HOLDING TANK SYSTEM:
• Ecomar™ waste treatment system (600Gal/day) x 2
BILGE / DISCHARGE:
• Oversized drains to overboard
• Automatic bilge pump - The vessel shall be outfitted with
automatic bilge pump with manual and automatic
switches in each space as divided by weather-tight
bulkheads.
• High water bilge alarm at every Rule® bilge pump
station
• Dry bilge area arrangement in center engine room
• Lighted bilge with built-in (when necessary) S/S ladder
(Unique OA Feature)
OTHER:
• Compressed air in ER & aft deck
AC / DC SYSTEM:
AC outlets throughout
• All primary AC & DC electrical wiring is appropriately
labeled throughout the yacht
• GFI (110V) AC outlet in potential “wet” areas. In addition,
entire boat is dual protected via ELCI Octoplex breakers.
(OA is unique in the industry to provide dual protection
GFCI & ELCI)
• 24 Volt system
• Engine battery isolation switches
• AGM Batteries with 40°F to 140°F operating temp and
industry leading low self-discharge rates 1 to 3%
Octoplex NMEA 2000 Monitor Network electrical control
system
• Based on aerospace technology for remote activation,
control and status reporting of AC and DC breakers.
Monitors power sources (AC and DC) for voltage,
frequency and amperage abnormalities and provide
visual and audio alerts. Includes enhanced circuit
breaker functionality with no-load indication, dimming
and usage information with touch screen monitor that is
user reconfigurable. Brown-out configurable control
through auto load shedding is included where operator
designated equipment (e.g. navigation and other
essential systems) remains powered-on while
automatically switching other systems off. Octoplex
NMEA 2000 Vessel system monitor system. Provides main
access doors, tank levels, bilge level and battery
monitoring of current, voltage and temp. (Unique OA
standard feature, not an optional upcharge like
competitors)
• Heavy-duty batteries
• Battery paralleling system w/ control switch
• Service battery switch
• Bonding system throughout
• The vessel's bonding and grounding systems shall
include copper straps secured to the hull and running
the full length of the vessel parallel to centerline. Engines,
generators, metallic through hulls, strainers, and pump
bodies shall be connected to the bonding strap using 8
AWG wire minimum or equivalent
AIR CONDITIONING
Dometic® chilled water system air conditioning system,
rated for “extreme tropical climates” (with reverse cycle
for operation down to 40°F water temp)
• Refrigerant type is accepted worldwide under the
Montreal Protocols
• Dedicated engine room air conditioning
• Where possible A/C exits from custom made ceiling
panels hidden from view. Shortens A/C ducting thus
improving efficiency and speed of cooling by over 20%.
Also reduces db reading by over 7 db (Design cues from
135)
LIGHTING:
• 24V LED lights (Aerospace quality, specially tuned color
temperature for Ocean Alexander
• Convenience lights
• International navigation lights
NAVIGATION PACKAGE:
• Garmin 8600 series black box with 24” touch screen
(three screens skylounge station)
• Garmin GRID remote input device installed on helm
chair
• Garmin 25KW open array radar
• Garmin autopilot GHC20
• Garmin VHF and card reader
• Garmin blackbox sounder
• Garmin AIS with NMEA GPS
• Garmin marine camera (2 in engine room and 1 aft
deck)
• KU-KA-band triad technology HD7 with direct HDTV
• Ritchie compass 5"
• IPad with built-in Garmin app for navigational
control/viewing via iPad
• Navigational electronics standard versus optional with
competitors
N2KVIEW SAFETY & SECURITY MONITORING PKG:
• These security/safety automatic monitoring and alert
abilities include using Apple iPad or Android for wireless
access to operate, view, and alarm Octoplex data and
navigation system with a fully customizable screen
layout, and remote notification (cell phone) capability
• These monitoring abilities include: main engines and
generators, AC monitoring, DC house bank battery
monitoring, engine room weather-tight bulkhead door,
tank Levels, fire System, bilge level (high-water), exterior
door sensors . Unique OA standard feature, not an opt
upcharge like competitors
POWER CONVERTER PACKAGE:
• Atlas 50/60 Hz power converter. Allows for automatic
marina connection irrespective of 60 Hz (USA) or 50 Hz
(European) standards.
• 100AMP charger
OTHER:
• Vimar™ switches and outlets
• Panasonic Intercom system – includes Panasonic phone
system and digital panasonic phones for connection in
MSR, VIP,guest staterooms, crew lounge, salon, galley
and skylounge
• ACR searchlight with 1,000,000 peak candlepower and
spreader lights for swim step and FB deck
• Onboard intranet, driven by commercial-grade 4G SIM
card capable Wi-Fi router. Allows outside 4G Internet
card and/or internal intranet net connection via supplied
iPad to Systems monitoring, Garmin and other onboard
equipment apps. (Unique OA feature)
• Shore power receptacles in transom with CM-8 cable
master storage system. (OA is unique in making this a
standard vs. optional. Cleans & boosts questionable
shore power to better protect sensitive equipment
onboard)
MAIN DECK MASTER STATEROOM:
• LED 50” flip down TV with A/V System
• King-sized berth (with independently coiled his & her
sections to ensure minimal transfer of movement)
• Two nightstands with wood countertop
• Hidden safe in hanging locker
• Walk-in closet on FWD w/ lighting
• Wide-opened curved window with custom engineered
solution incorporating aluminum beams allows greatest
visibility and incoming light
• Custom headboard with recessed indirect lighting
• Vanity on port, sofa with table on starboard
SKYLOUNGE :
• Cabinet including wet bar, Jenn-Air™ refrigerator w/
doors and storage
LED 50” flip down TV with A/V System
• Wood valance board
• Settee with wood table
• Day head
• Chart locker
• Phantom screen (for insects + pollen protection) with
dedicated wood box for door
• Electric Stidd helm seats x3
TWIN VIP STATEROOM:
• LED 50” TV
• Double berth
• Two nightstands with wood countertop
• Vanity table with chair
• Walk-in closet
• Storage cabinets
TWIN GUEST STATEROOM:
• LED 24” TV
• Nightstands with wood countertop
• Cedar-lined, Full-height hanging locker with lighting
• Side-by-side berths can slide together and convert to
single queen berth.
SALON:
LED 60” flip down TV with blue-ray A/V system
• Wood paneling and cabinetry
• Evan K Marshall custom design salon furniture and sofa.
Sofa includes concealed drawers for intelligence use of
space and increase storage
• Stone countertops at wet bar, entertainment cabinet,
stbd cabinet front wall cabinet and dining room divider
cabinet
• Custom designed window mullion
• Decorative ceiling treatment
• Phantom screen (for insects + pollen protection) with
dedicated wood box for door
• Enlarged windows in salon with custom engineered
solution incorporation marine grade aluminum beams
allowing for industry leading window expanse.
Incorporate (where possible) A/C outlet from ceiling,
provides unobstructed view to outside (Design cues from
135, improved for 2017)
• Sylomer floating floor and wall
• Sub Zero™ refrigerator
• Salon custom wood floor in lieu of carpet
CREW QUARTERS:
• Largest crew quarters in its class with Ocean Alexander’s
unique design, the crew quarters doubles as a Cabana.
Allows for day head and rest/eat area for swimming/out
of water activities without needing to access salon/main
deck interiors
• LED 32” TV at captain stateroom with satellite receiver
Cedar-lined hanging locker with automatic lighting in
captain stateroom
• Kitchenette (sink, microwave, cooktop and refrigerator
w/ice maker)
• Storage locker
• Drawers under bunk
• Microwave Oven
• Captain quarter includes desk with storage and N2KView
linked Apple ipad for systems diagnostics/alerts/settings.
Full height hanging closet and queen size berth with
storage under
• Dedicated stainless work bench and Snap-on tool chest.
Also includes a wet locker (with ventilation and separate
water drain) and storage compartment. All staterooms
fully air-conditioned
• LED 40” TV with satellite receiver at crew lounge
• Crew quarter w/private head & shower
INTERIOR DÉCOR:
• Wood paneling and cabinetry in semi-gloss
• Walnut wood satin finish
• Interior ceiling panels removable and finished with
diamond faceted edging. Provides a sharper and
structured tailored look. (Design cues from 135)
• Evan Marshall designed interior pilot station and display
pod. With matching wood w/ Faux leather and “floating”
display pod. Ergonomically designed and laid out to
enhance pilot experience/performance. (Design cues
from 135)
• Custom designed and water jet cut stone with stainless
steel insert in lower foyer and master bathroom. (Design
cues from 135)
• Carbon monoxide and smoke detectors
• Air extraction in each head shall be by low noise
extraction fans, switched separately from lights
• Opening port holes for staterooms and twin VIP heads
• High quality European door locks
• Cedar-lined, hanging locker with auto lighting
• Fabric covered walls for lower walkway walls
• Concealed hinges throughout interior cabinets
• Ergonomically designed mattresses and settees
• Washer/ dryer (Commercial quality, Energy star
washer/dryer) in lower foyer
• Danby refrigerator in lower foyer
• $70,000 décor allowance for carpet, bed spreads, and
soft goods
• Electrical blinds for salon, dining, and master(excluding
dayhead) and skylounge (excluding dayhead)
• USB power plug at skylounge counter top and inside MSR
nightstand
• Dedicated oversized drawer for golf club/sport
rackets/bulky items storage under MSR berth
• Crestron Audio/Video & lighting control package
GALLEY:
• Wood panel and cabinetry with positive-latch doors or
proprietary drop-lock drawers. Provides containment of
stored objects while underway (Std. feature often ignore
by competitor)
• Galley storage cabinetry w/hidden hinges
• Stone countertop
• Stone floor in galley
• Elkay™ professional series kitchen sink w/ pull out tap
• Overhead dish locker fwd & stbd
• 30” Thermador™ electric cook top
• 30” Thermador™ electric oven
• Sub-Zero® Refrigerator/ freezer
• Sub-Zero® ice maker
• Sub-Zero® wine cooler
• Whirlpool™ garbage disposal
• 30" Viking™ Over-the Range Microwave with exhaust
blower
• Thermador™ dishwasher
• 15” Whirlpool™ trash compactor
• Seagull™ water purifier (ADEX design award winner w/
filtration to 0.1 microns & EPA certification for
microbiological purification)
• Custom s/s potholder for cook top
• Kessebohmer magic corner storage
HEADS:
• Wood paneling and cabinetry
• Stone countertop with china sink
• Seamless fiberglass stall shower w/ one-piece glass door.
Industry leading seamless one-piece shower stall design
provides long term protection against moisture, water
intrusion behind the shower panels - leading to foul odors
and water damage (Unique OA feature)
• Shower door w/ stones frame. shower door shall use
“crystal clear” glass custom made for Ocean Alexander.
Providing superior transparency and reflectiveness.
Together with custom made for Ocean Alexander
“minimalist and transparent water strips” provides a
unique Ocean Alexander proprietary “Crystal Shower”
• Cabinet with mirror door above sink
• Air extraction in each head shall be by low noise
extraction fans
• Planus™ toilet system throughout with unique Ocean
Alexander proprietary “Toilet lock out” system. Provides
“lock out” of flushing when holding tank is full. Prevents
accidental spillage or “blow back” often found on
competitor yachts. Tankage status and alarm is standard
via N2KView monitoring system.
• Custom bathroom fixtures
• Heated stone floor on MSR heads
EXTERIOR:
• Roof top with dedicated custom S/S ladder to
navigational electronics (Standard versus optional with
competitors)
• 2” elliptical 316L stainless steel handrails & stanchions,
main deck 1-1/2” on FB. Elliptical conforms better to
human grip than traditional round rails. Provides greater
“grip strength” for safety and comfort (Unique OA feature)
• 316 stainless-steel cleats
• Elec. stainless-steel sliding doors for salon and skylounge
with safety light curtain that senses obstruction and
protect for grandkids/pets. Also includes “foot-kick
button” control for operation when both hands with full
food trays/other items.
• Two S/S flag poles, Fore and aft
• Teak and stainless steel swim ladder, foldable
• Weather-tight door on transom for access to engine
room/ crew quarters
• White non-skid fly bridge deck
• 32” Electric-Chef™ electric barbecue custom-made for
OA using 316 S/S, versus competitors’ 304 materials.
• Boat deck seat w/storage underneath and stone table
• Fiberglass stairway up to flybridge from cockpit w/teak
steps
• Teak deck for aft deck and walkway to midship
• Teak swim platform w/ teak steps
• High bulwark w/ flush-mounted deck lights
• Side boarding gates in cockpit
• Recessed boarding ladder on starboard gunnel with OA
logo teak steps (Unique Ocean Alexander standard
feature. Competitors either optional or not available)
• Boat deck outboard storage increased by 54% via
additional storage lockers on port and starboard where
possible
• Exterior ceiling panels removable and finished with
diamond faceted edging. Provides a sharper and
structured tailored look. Also allows for easy service of
navigational electronics and plumbing runs. (Design
cues from 135)
• Custom designed fender storage at bow/chain
locker/lazarette
• Bow seating w/ concealed pop-up lighting and hi-lo
table convert to sun pad and exterior speakers w/ audio
streaming ability
• High output LED underwater lights x 8
• S/S transom gates for pets/children protection
• ACR searchlight with remote on skylounge
• Pre-plumbing and wiring for Jacuzzi
• Manual awning for flybridge with custom made stainless
steel poles and marine-grade exterior. Ferrari mesh
fabric. Includes custom designed built-in storage for
poles.
• Manual awning for bow with custom made stainless steel
poles and marine-grade exterior. Ferrari mesh fabric.
Includes custom designed built-in storage for poles
• Custom exterior protection canvas and windshield mesh
cover for exterior seating and BBQ
• Flip down 32” TV from ceiling TV with satellite receiver
includes additional exterior speakers for full stereo effect
on fly bridge. Includes Bluetooth streaming ability direct
to exterior TV and speakers
• Flip down 40” TV from ceiling TV with satellite receiver
includes additional exterior speakers for full stereo effect
on aft-deck. Includes Bluetooth streaming ability direct to
exterior TV and speakers
• Aft-deck custom ceiling feature
• Boat deck sliding hatch
• 8-man life raft x 2 in valise bag
