Asking
Inquire for price

ARISTARCHOS Yacht for Sale

Length
131' 2" (40m)
Builder
Nautor Swan
Build
2006/2022
Guests
8
Cabins
3
Crew
6
Asking Price
Request

Not for sale or charter to U.S. residents while in U.S. waters.

“Nautor’s Swan is renowned delivering the finest composite sailing yachts built to the designs of German Frers for over 70 years. ARISTARCHOS is the largest of the Swan fleet to date and a testament to the Nautor style and quality. Sparingly sailed locally in her Greek waters by her original owner and fully maintained since her launch, she has very low hours of use and is in exceptional condition.”

Commercially compliant and EU VAT Paid.

Northrop and Johnson is pleased to assist you in the purchase of this vessel. This boat is centrally listed by Fraser Yachts. It is offered as a convenience by this broker/dealer to its clients and is not intended to convey direct representation of a particular vessel

Amenities

  • Personal Watercraft
  • Wi-Fi

Specifications

Builder Nautor Swan
Model swan 131
Length (LOA) 131' 2" (40m)
Year 2006
Year Refit 2022
Gross Tonn. 185
Draft 16' (4.88m)
Beam 27' 10" (8.5m)
Range 2,000 NM
Location Greece

Accommodations

Staterooms 3
Sleeps 8
King Beds 2
Twin Beds 2
Heads 3
Crew Cabins 3
Crew Sleeps 6
Capt. Quarters No

Dimensions & Capacity

LOA 131' 2" (40m)
LWL 114' (34.69m)
Max Draft 16' (4.88m)
Fuel Tank 3,170 g (12,000 L)
Fresh Water 1,004 g (3,800 L)
Holding Tank 374 g (1,415 L)
Gross Tonn. 185
Displacement 235

Construction

Hull Material Fiberglass
Hull Config Monohull
Ext. Designer german frers
Int. Designer rhoades young
Max Speed 13.5 Knots
Cruising Speed 12 Knots
Range 2,000 NM
Stabilizers None

Engines (x2)

Engine Make CATERPILLAR
Engine Model C12
Engine Type Inboard
Power HP 480
Power KW 358
Fuel Type Diesel
Engine Location Port
Have Questions?

Complete the form below and one of our experienced sales brokers will be in touch soon.

Full Details

Other Machinery

  • Frequency converter: ASEA power System 29 kw
  • Shore cable: 3 x 125 A - 5 poles, 40mm diameter cable
  • Main power system: 24 VDC from total 2250 Ah batteries and 220 VAC from inverters or generators
  • Lighting: 24 VDC
  • Battery chargers: 600 A charging system X 8 units
  • Batteries: 12x2Vcells=1500Ahat24VDC, 12x2Vcells=750VDCat24VDC 4 x 12V main engine starters, 4 x 12V generator starters, 2 x 12V radio
  • Dirty Lub Oil: 140 lt
  • Steering system & controls: 2 x twin hydraulic Bosch Rexroth, 3 x pumps, 2 x Simrad control units
  • Rudders: twin rudder system with shafts & clutch
  • Watermakers: 2 x Idromar MC8 duplex - 600 lt/hr/each
  • Water pressure system: 2 x Gianneschi 3 pumps 220 VAC
  • Water boiler: 400 lt with 2 x 3 kw resistors and hot water circulator
  • Wash-down system: 2 x hoses (bow & stern)
  • A/C: 200,000 BTU 17 fans - 4 x compressors and chillers Condaria
  • Ventilation engine room: 2 x Novenco exhaust-inlet fans and 2 x fan coils (cooling)
  • Fresh air throughout
  • Compressed air system: 2 x compressor 220 VAC and 24VDC
  • Compressed air outlet: bow, stern, engine room
  • Hydraulic pack: 2 x AC pumps 400VAC 5,5kw & 11kw
  • Racor water separator filters
  • Fuel transfer pumps: 3 x pumps (main, hand pump and tender refuelling)

Accommodation

Guest accommodations

  • 1 Master suite with 2 king size beds, two walk-in closets, dressing and office table
  • 1 VIP with 1 queen and a pull-man bed
  • 1 twin with 2 single beds
  • All cabins with ensuite facilities

Crew accommodations

  • One cabin with 1 x berth
  • One cabin with 2 x berths
  • One cabin with 3 x berths
  • All crew cabins with ensuite facilities

Galley & Laundry Equipment

  • Bosch ceramic induction 4 x rings stove cooker (2020)
  • Gaggenau 90cm wide oven
  • TEKA electric grill 30cm with lava stones (2020)
  • 2 x NEFF built-in refrigerators 400 lt/each
  • 1 x wine cooler
  • 1 x refrigerator on deck
  • 1 x NEFF built-in freezer 350 lt (2020)
  • Dishwasher Miele Pro
  • Icemaker in galley & salon
  • Waste disposal Insinkerator model 57 (2020)
  • Washer Miele Pro
  • Dryer Miele Pro

Communication Equipment

  • Fleet 55 Satellite Communications
  • AIS: Nauticast
  • VHF: 2 x Sailor 6222 DSC
  • VHF handheld: 6 x Icom IC M57
  • SSB: Furuno
  • Satcom: 2 x Inmarsat C units
  • Telephone system: Panasonic
  • Intercom system: Panasonic
  • Cellular phone system: yes
  • Wi-Fi
  • Chart table navigation communication room below deck

Navigation Equipment

  • 2 x Furuno 1956c radars
  • Echosounder: B&G & Furuno
  • GPS: Furuno GP-150 & GP-90
  • Plotter: Furuno Navnet 2
  • Wind instruments: B & G
  • Speedlog:B&G
  • Gyrocompass: Sperry Marine
  • Autopilot: Simrad AP25
  • Magnetic compass: Silva
  • Navtex: Furuno

Entertainment Equipment

  • Salon: BOSE cinema system with Philips 43" TV
  • Cabins: BOSE 321 system with subwoofer and 21" TV
  • Sundeck/fly: Denon system with 6 x speakers

Tenders & Toys

Tenders:

  • 1 x jet Castoldi 5.50m with 125 HP Yanmar
  • 1 x Zodiac 3.80m with 15 HP Yamaha

Diving equipment:

  • Bauer 320 bar compressor - 2 x diving tanks

Deck Equipment

  • 2 x Xenon lights at stern
  • 2 x 8000 Lewmar anchor windlasses
  • 2 x stainless steel Niro Petersen 135 kg anchors
  • 2 x 120m stainless steel chains 16mm
  • C-Quip carbon crane 1500 kg SWL for the tender (overhauled in 2020) C-Quip carbon folding passerelle
  • C-Quip side boarding ladder
  • Swinging-out aft carbon swimming platform
  • 2 x Marco searchlights
  • Bimini, spray hood & sun awning

OFFICE EQUIPMENT

  • Computer
  • Printer

Rigs & Sails

  • SHOUTHERN SPARS carbon keel stepped mast 54 meters, carbon spars and spreaders, carbon boom, with in- boom furling mandrel and hydraulic furling motor (mast was unstepped at 2020 by A+ Rigging Majorca, repainted with Awlgrip)
  • BSI rod rigging and fittings all are replaced with new, at 2020
  • All Running Rigging, halyards and sheets are replaced, new at 2020 - total Sail Area 989 square meters
  • NORTH SAILS Main 3Di(2017), Jib 3Di(2015) and Staysail 3DL(2006)
  • RECKMANN Jib and Staysail hydraulic furlers (overhauled at Reckmann Germany at 2020)
  • RONDAL captive hydraulic winches for the Jib sheets, for the Main sheet, the Main halyard and the running backstays
  • LEWMAR hydraulic winches by the mast and at the aft deck

Safety & Security Equipment

  • Alarms and communications: PLC alarm monitoring system
  • Safe in master and captain's cabin
  • 3 x liferafts for 8 pax each
  • Medical kit
  • Fire alarms throughout Bilge alarms
  • Burglar alarms

Fire fighting:

  • Automatic fire fighting in engine room, electric panels and bilges
  • 14 x portable fire extinguishers
  • 2 x fire hoses

Refit History

2020-2021

  • A+ Rigging: a full Level A Visual rigging inspection including check of mast jack pressure December 2020.
  • Next rigging inspection will be on December 2021

2019-2020

  • Mast was pulled out by A+ Rigging
  • All the rigging rods and fittings are fabricated new from BSI
  • All the halyards are coming new from Mallorca after being spliced at the ends
  • The 54 meters carbon fiber mast, the boom, spreaders and boom-vang were painted with Awlgrip (snow- white 2000)
  • Profesional Paintworks
  • Both Reckmann hydraulic furlings were sent to Reckmann for service
  • The sails were sent to Kafetzidakis Sails for washing maintenance and storage
  • The hydraulic crane for the Castoldi boat was overhauled, the motor and the 3 hydraulic cylinders were serviced
  • All 6 hydraulic cylinders from the rigging were overhauled and serviced
  • Both JP3 rudders were pulled out for service
  • All the 24 sea valves are pulled out and will be replaced with new ones. New elastic sea pipes are installed. Upgrade the electronic controls for main engines end generators
  • To replace all the plexi-glass on the deck hatches
  • A new induction stove and new grill are installed in the galley
  • All the air condition system, fan coils, air handles, and air ducting were cleaned and sanitized The teak deck to be sanded fresh.
  • Top sides and superstructure to be polished
  • All the works are followed by Bureau Veritas
