“Nautor’s Swan is renowned delivering the finest composite sailing yachts built to the designs of German Frers for over 70 years. ARISTARCHOS is the largest of the Swan fleet to date and a testament to the Nautor style and quality. Sparingly sailed locally in her Greek waters by her original owner and fully maintained since her launch, she has very low hours of use and is in exceptional condition.”

Commercially compliant and EU VAT Paid.

Northrop and Johnson is pleased to assist you in the purchase of this vessel. This boat is centrally listed by Fraser Yachts. It is offered as a convenience by this broker/dealer to its clients and is not intended to convey direct representation of a particular vessel

View Yacht for Charter

Amenities

Jacuzzi
Personal Watercraft
Wi-Fi

Specifications

Builder	Nautor Swan
Model	swan 131
Length (LOA)	131' 2" (40m)
Year	2006
Year Refit	2022
Gross Tonn.	185
Draft	16' (4.88m)
Beam	27' 10" (8.5m)
Range	2,000 NM
Location	Greece

Accommodations

Staterooms	3
Sleeps	8
Heads	3

Crew Cabins	3
Crew Sleeps	6
Capt. Quarters	No

Dimensions & Capacity

LOA	131' 2" (40m)
LWL	114' (34.69m)
Max Draft	16' (4.88m)
Fuel Tank	3,170 g (12,000 L)
Fresh Water	1,004 g (3,800 L)
Holding Tank	374 g (1,415 L)
Gross Tonn.	185
Displacement	235

Construction

Hull Material	Fiberglass
Hull Config	Monohull
Ext. Designer	german frers
Int. Designer	rhoades young
Max Speed	13.5 Knots
Cruising Speed	12 Knots
Range	2,000 NM
Stabilizers	None

Engines (x2)

Engine Make	CATERPILLAR
Engine Model	C12
Engine Type	Inboard
Power HP	480
Power KW	358
Fuel Type	Diesel
Engine Location	Port

Full Details

Other Machinery

Frequency converter: ASEA power System 29 kw
Shore cable: 3 x 125 A - 5 poles, 40mm diameter cable
Main power system: 24 VDC from total 2250 Ah batteries and 220 VAC from inverters or generators
Lighting: 24 VDC
Battery chargers: 600 A charging system X 8 units
Batteries: 12x2Vcells=1500Ahat24VDC, 12x2Vcells=750VDCat24VDC 4 x 12V main engine starters, 4 x 12V generator starters, 2 x 12V radio
Dirty Lub Oil: 140 lt
Steering system & controls: 2 x twin hydraulic Bosch Rexroth, 3 x pumps, 2 x Simrad control units
Rudders: twin rudder system with shafts & clutch
Watermakers: 2 x Idromar MC8 duplex - 600 lt/hr/each
Water pressure system: 2 x Gianneschi 3 pumps 220 VAC
Water boiler: 400 lt with 2 x 3 kw resistors and hot water circulator
Wash-down system: 2 x hoses (bow & stern)
A/C: 200,000 BTU 17 fans - 4 x compressors and chillers Condaria
Ventilation engine room: 2 x Novenco exhaust-inlet fans and 2 x fan coils (cooling)
Fresh air throughout
Compressed air system: 2 x compressor 220 VAC and 24VDC
Compressed air outlet: bow, stern, engine room
Hydraulic pack: 2 x AC pumps 400VAC 5,5kw & 11kw
Racor water separator filters
Fuel transfer pumps: 3 x pumps (main, hand pump and tender refuelling)

Accommodation

Guest accommodations

1 Master suite with 2 king size beds, two walk-in closets, dressing and office table
1 VIP with 1 queen and a pull-man bed
1 twin with 2 single beds
All cabins with ensuite facilities

Crew accommodations

One cabin with 1 x berth
One cabin with 2 x berths
One cabin with 3 x berths
All crew cabins with ensuite facilities

Galley & Laundry Equipment

Bosch ceramic induction 4 x rings stove cooker (2020)
Gaggenau 90cm wide oven
TEKA electric grill 30cm with lava stones (2020)
2 x NEFF built-in refrigerators 400 lt/each
1 x wine cooler
1 x refrigerator on deck
1 x NEFF built-in freezer 350 lt (2020)
Dishwasher Miele Pro
Icemaker in galley & salon
Waste disposal Insinkerator model 57 (2020)
Washer Miele Pro
Dryer Miele Pro

Communication Equipment

Fleet 55 Satellite Communications
AIS: Nauticast
VHF: 2 x Sailor 6222 DSC
VHF handheld: 6 x Icom IC M57
SSB: Furuno
Satcom: 2 x Inmarsat C units
Telephone system: Panasonic
Intercom system: Panasonic
Cellular phone system: yes
Wi-Fi
Chart table navigation communication room below deck

Navigation Equipment

2 x Furuno 1956c radars
Echosounder: B&G & Furuno
GPS: Furuno GP-150 & GP-90
Plotter: Furuno Navnet 2
Wind instruments: B & G
Speedlog:B&G
Gyrocompass: Sperry Marine
Autopilot: Simrad AP25
Magnetic compass: Silva
Navtex: Furuno

Entertainment Equipment

Salon: BOSE cinema system with Philips 43" TV
Cabins: BOSE 321 system with subwoofer and 21" TV
Sundeck/fly: Denon system with 6 x speakers

Tenders & Toys

Tenders:

1 x jet Castoldi 5.50m with 125 HP Yanmar
1 x Zodiac 3.80m with 15 HP Yamaha

Diving equipment:

Bauer 320 bar compressor - 2 x diving tanks

Deck Equipment

2 x Xenon lights at stern
2 x 8000 Lewmar anchor windlasses
2 x stainless steel Niro Petersen 135 kg anchors
2 x 120m stainless steel chains 16mm
C-Quip carbon crane 1500 kg SWL for the tender (overhauled in 2020) C-Quip carbon folding passerelle
C-Quip side boarding ladder
Swinging-out aft carbon swimming platform
2 x Marco searchlights
Bimini, spray hood & sun awning

OFFICE EQUIPMENT

Computer
Printer

Rigs & Sails

SHOUTHERN SPARS carbon keel stepped mast 54 meters, carbon spars and spreaders, carbon boom, with in- boom furling mandrel and hydraulic furling motor (mast was unstepped at 2020 by A+ Rigging Majorca, repainted with Awlgrip)
BSI rod rigging and fittings all are replaced with new, at 2020
All Running Rigging, halyards and sheets are replaced, new at 2020 - total Sail Area 989 square meters
NORTH SAILS Main 3Di(2017), Jib 3Di(2015) and Staysail 3DL(2006)
RECKMANN Jib and Staysail hydraulic furlers (overhauled at Reckmann Germany at 2020)
RONDAL captive hydraulic winches for the Jib sheets, for the Main sheet, the Main halyard and the running backstays
LEWMAR hydraulic winches by the mast and at the aft deck

Safety & Security Equipment

Alarms and communications: PLC alarm monitoring system
Safe in master and captain's cabin
3 x liferafts for 8 pax each
Medical kit
Fire alarms throughout Bilge alarms
Burglar alarms

Fire fighting:

Automatic fire fighting in engine room, electric panels and bilges
14 x portable fire extinguishers
2 x fire hoses

Refit History

2020-2021

A+ Rigging: a full Level A Visual rigging inspection including check of mast jack pressure December 2020.
Next rigging inspection will be on December 2021

2019-2020

Mast was pulled out by A+ Rigging
All the rigging rods and fittings are fabricated new from BSI
All the halyards are coming new from Mallorca after being spliced at the ends
The 54 meters carbon fiber mast, the boom, spreaders and boom-vang were painted with Awlgrip (snow- white 2000)
Profesional Paintworks
Both Reckmann hydraulic furlings were sent to Reckmann for service
The sails were sent to Kafetzidakis Sails for washing maintenance and storage
The hydraulic crane for the Castoldi boat was overhauled, the motor and the 3 hydraulic cylinders were serviced
All 6 hydraulic cylinders from the rigging were overhauled and serviced
Both JP3 rudders were pulled out for service
All the 24 sea valves are pulled out and will be replaced with new ones. New elastic sea pipes are installed. Upgrade the electronic controls for main engines end generators
To replace all the plexi-glass on the deck hatches
A new induction stove and new grill are installed in the galley
All the air condition system, fan coils, air handles, and air ducting were cleaned and sanitized The teak deck to be sanded fresh.
Top sides and superstructure to be polished
All the works are followed by Bureau Veritas
