SUNRISE Yacht for Sale

Shafting:

• ASTUCCIO, water lubricated bearing shaft line for each propulsion set.
• Shaft material is Aquamet 17, diam. 110 mm.

Propellers:

• Two high skewed propellers made by five nickel aluminium-bronze blades and hub.
• Each propeller is statically balanced manufacturing tolerances are according to ISO 484/2 CLASS S.

Engine Ventilation:

• Two axial flow fans (Gianneschi ELL/AP 457/3), for intake.
• Two centrifugal flow fans (Gianneschi VCR 351/B), for exhaust.

Shore Power:

• CANTALUPI
• 1x 100A shore power inlet sockets
• 1x 20 m shore power cables of suitable section
• Shore Power Transformer:    1x 70kVA 400V (inlet) / 400V (outlet), 3 phases + neutral, 50Hz shore insulating transformer

Batteries:

• One group of 24V DC batteries for emergency
• One group of 24V DC batteries for radio equipment’s
• One group of 24V DC batteries for service
• Two groups of 24V DC batteries for main engines starting
• Two groups of 24V DC batteries for diesel generators starting
• Battery Chargers:    1 x main engine battery sets charger provided with charging
• divider, MASTER VOLT/24/20-3
• 1 x diesel generator battery sets charger provided with charging divider, MASTER VOLT/24/75-C
• 1 x service battery set charger, MASTER VOLT/24/20-3
• 1 x emergency battery set charger, MASTER VOLT/24/20-3
• 1 x radio battery charger, MASTER VOLT/24/20-3
• 1 x back-up radio/service/emergency sets charger, MASTER VOLT/24/20-3

UPS (uninterruptible power supplies):

• 1x UPS rack mount

Steering System:

• WORLD YACHT (manufacturer), consist of the following components:
• 1 x electrical actuator in the wheelhouse
• 1 x double electrohydraulic power pack in the aft port technical room
• 2 x cylinders (one for each rudder)
• Tiller arm joined by interconnecting rod
• Interface with autopilot
• Steering Gear:    WORLD YACHT (manufacturer), steering gear motor start panel provided with:
• Alarm for overload
• Single phasing
• Loss of power
• Emergency Steering:    WORLD YACHTS (manufacturer)

Bow Thruster:

• DUALIS ELECTRA /TP40 Electric motor driven bow thruster (CMC BTM60) with the following features:
• Power: 52 kW/ 400VAC 3 ph
• Insulation Class of electric motor: F
• Protection degree of electric motor: IP 23
• Service factor of electric motor: S6 - 40%
• Inside tunnel diameter: about 500 mm
• Nominal thrust (without grid): 8,1 kN. A thrust reduction of 20% with the installation of tunnel grids
• Control joystick installed on the wheelhouse console and on wings control panels

Stabilizers:

• One pair of stabilizer fins (CMC Stabiliser Electra SE80-7-4-160) for underway operation and at anchor as well.
• The fins are provided with an electrical motor having 7 kW input nominal power supplied by generators
• Fin area is 1.6 m2
• Control panel 24 V DC installed in the wheelhouse
• Voltage is 400 Vac, 3 phases, 50Hz, duty cycle S1

Helm/Wing Station Controls:

• Two control stations with 3.5” multifunction displays positioned externally at both sides of the wheelhouse including all the necessary commands and instruments for manoeuvring the Yacht in mooring operations, that is:
• Steering tiller
• Slave bow thruster control lever
• Horn
• Main engine throttles
• MMEE start/stop buttons and alarm signal, emergency stops
• NMEA DATA


Fuel & Oil System

• Common Rail direct fuel injection with electronic control
• Fuel Filters:    Filters, equipped with vacuum gauges and water sensor, installed for main engines and diesel generators:
• Main engines: a two elements filter (one working, one spare), each fitted with by-pass, according to the main engines manufacturer instructions
• Diesel generators: a two elements filter (one working, one spare), each fitted with by-pass, according to the diesel generators manufacturer instructions
• Fuel Transfer Pump:    1 x electric transfer pump Gianneschi ACB 331 400Vac, flow rate, 120lt/min, 31usg/min at 9m H2O)
• 1 x Planus grey water transfer unit
• 1 x hand pump as emergency Gianneschi Super Lario 3, flow rate 50lt/min, 13usg/min at 30m H2O
• Dirty Oil Pump:    1 x electric dirty oil pump Gianneschi PQ40 400Vac, flow rate 40lt/min 10.5gals/min at 50m H2O
• Lubrication Oil Pump:    1 x electric Gianneschi PQ40 400Vac, flow rate 40lt/min 10.5gals/min at 50m H2O) clean oil pump


Firefighting & Bilge Pump:

• 1 x Gianneschi GK17/2/330 (emergency fire pump)
• 1 x Gianneschi GK17/2/330 (bilge suction pump)
• 1 x LOMBARDINI/15-LD-500


Fresh Water System
Fresh Water Pump:

• 2 x electrical pumps Gianneschi CSX 804 400Vac, flow rate 180lt/min, 47usg/min to 20m H2O

Fresh Water Makers:

• 1 x reverse osmosis water maker Idromar MC3J) Nominal capacity 4,300 litres (1135usg) of water per day at 25° C sea water temperature.
• 1 x reverse osmosis water maker Idromar MC9S mini 450 litres/hour
• Hot & Cold Circulation Pump:    2 x hot water circulating pumps Gianneschi Z25 400Vac
• Hot Water Boilers:    2 x Gianneschi electric hot water stainless steel heaters with capacity of 150 litres (39usg) each fitted. Resistance 3+3kW for each heater
• Sea Water Pumps:    2 x WİLO/STARZ25/2


Garbage Management System
Garbage Compactor:

• 1 x Krushr
• 1 x Insinkerator



AC & Ventilation System
Air Conditioning:

• 2 x Frigomar 410 Series, Model 605 NT 160 000 BTU
• 1 x Mini Chiller Frigomar, Model 602 NT 45 000 BTU

Air Compressor:

• 1 x Gianneschi GK17/2/330

Engine Room Ventilation:

• 2 x Gianneschi (extraction)
• 2 x Gianneschi (ventilation)


Hydraulic System
Emergency Power Pack:

• 1 x Gianneschi 220v
• 1 x Gianneschi 240v
• 1 x Yanmar


Antifouling System
Type:

•  International Uni-Pro 250

OVERWIEW:

• The Interior’s styles are based on the Interior’s Concept Design, done by Benetti Style Department. Up to 10 guests are accommodated on board the superyacht SUNRISE, and she also has accommodation for 7 crew members including the captain of the vessel.

LOWER DECK:

• Port VIP Stateroom and Bath, Port Twin Stateroom and Bath, STBD VIP Stateroom and Bath, STBD Twin Stateroom and Bath, Lobby.

MAIN DECK:

• Main Saloon, Main Foyer, Galley, Pantry, Powder room, Owner’s Study, Owner’s Dressing, Owner’s Stateroom, Owner’s Bathroom.

BRIDGE DECK:

• Sky Lounge, Lobby, Powder Room, Wheelhouse.

CREW ACCOMODATION:
LOWER DECK:

• Crew Mess, STBD Crew Cabin and Bath, Port Crew Cabin and Bath, STBD Crew Cabin and Bath, Laundry, Crew Corridor.

UPPER DECK:

• Captain’s Cabin and Bath, Pantry.

MAIN GALLEY EQUIPMENT
Cooking Equipment:

• 1 x MIELE Cooking Top
• 1 x MIELE Oven
• 1 x MIELE Microwave
• 1 x MIELE BBQ grill

Refrigeration/Freezer:

• 2 x LIEBHERR 4260 Fridge
• 1 x LIEBHERR 3036 Freezer
• 1 x ISOTHERM Minifridge (1 x Upper Deck, 1 x Sun Deck)
• 2 x ISOTHERM Ice Maker (1 x Upper Deck, 1 x Sun Deck)

Dishwasher:

• MIELE


PANTRIES AND OTHERS
Wine Storage:

• 1 x LIEBHERR WU4500 Wine Cellar Pantry


CREW GALLEY / MESS EQUIPMENT / COOKING EQUIPMENT
Microwave:

• 1 x MIELE Microwave

Refrigeration/Freezer:

• 1 x ISOTHERM Minifridge

Dishwasher:

• 1 x MIELE/PG8056 Commercial Dishwasher

Main Laundry Equipment:

• 2 x MIELE Washing Machine
• 2 x MIELE Dryer Machine

OTHER EQUIPMENT

• Spa Tub:    Minipool (Jacuzzi Unique) fitted on forward area as per general arrangement with a 2kW heater
• Sauna:    1 x Tylo steam (master stateroom)
• Dumbwaiter:    Yes, from galley to upper deck

• VSAT:    SAILOR /V800 ACU
• VHF Radiotelephones:    2 x SAILOR 6215 VHF DSC
• Portable VHF:    3 x SAILOR SP3510 VHF
• Telephone System:    SNOM telephone, 1 x wheelhouse, 1 x galley, 1 x crew area and crew cabins. PANASONIC, 1 x master stateroom, 1 x each guest stateroom, 1 x main salon, 1 x upper deck.
• Intercom System:    PHONTECH/CIS3100
• Navtex Receiver:    FRUNO/NX-700B

• Monitors:    Series X - Maritime Multi Display (MMD) Models
• X-Band Radar:    Furuno, TZT2BB
• Chart Plotter:    2 x 15’’ Multifunction Display Furuno, TZT2BB, Furuno Navnet
• UPS:    Daker DK+
• Magnetic Compass:    Sperry Marine
• Gyrocompass:    Furuno/PG500
• Auto Pilot:    Navis 000 AP 50000
• Rudder Angle Indicator System:    Topcon
• Depth Sounder:    Furuno BBDS1
• GPS:    Furuno GP-330B
• AIS:    Furuno FA-170
• Wind Instruments:    Furuno BBDS1
• Horn:    Kahalenberg Air Horn
• Search Lights:    HR-1012U DC 24V
• Weather Station:    Airmar 220 WX
• Ships Computer:    Lenova

Video Equipment:

• Blusteam HEX100ARC-KIT V2
• 6 x TV Sony Bravia KDL32WE615B
• 2 x TV LG 28TN515S
• 8 x Sony Blu-ray Disc™
• DVD Player
• Apple TV

Audio Equipment:

• Bowers & Wilkins speakers – Marine 6, Marine 8
• Bowers & Wilkins speakers – 600 series Subwoofers

Control:

• 7 x iPad Mini

IT:

• Peplink - Pepwave MAX
• Crestron 3-Series Control Systems

WIFI:

• 4G & WIFI ANTENNA 4G-LTE CONNECTION Ubiquiti Unifi - UAP-AC-PRO

• Tenders:    Williams 505 Diesel jet 2021
• Jet Skis:    Seadoo gtx 300 limited
• Toys:    2 x Seabob F7

• Anchors:    2 x Hall steel anchor
• Anchor Chains:    2 x 110 meters steel chain
• Anchor Windlass System:    2 x Rossi
• MZ ELEKTRONIC digital chain counter
• Cranes:    2 x Pizzato (tender garage)
• Warping Capstans:    ITALWINCH/MILOS INOX
• Passerelle:    1 x MOR SAVERIO 079 T
• Side Boarding Ladder:    2 x Benetti custom made
• Swimming Ladder:    1 x stainless steel
• Paint Exterior:    Awlgrip and Awlcraft

CCTV:

• DAHUA
• Eco Savvy 3.0|2MP IR Mini Dome Network camera
• Pro Series 4MP 30x PTZ Network Camera
• Pro Series 16/32/64Channel 1.5U 4K&H.265 Pro Network Video Recorder

Fixed Firefighting System:

• MARİN FIRE /FM200

Smoke Detection:

• AUTROPRIME

Life Rafts:

• SURVITEC ZODIAC

Medical Equipment:

• First Aid Kit
